Electric Flexible Printed PCB Rigid Board Multilayer Circuit Board

MOQ : 100

Model NO. : HC-FPC-011

Material : Complex

Flame Retardant : V2

Mechanical Rigid : Fexible

Processing Technology : Electrolytic Foil

Base Material : Aluminum

Insulation Materials : Organic Resin

Wire Resistance : ≤ 1 Ohm/cm

Current Rating : 25-100mA, 0-30V DC

Work Voltage : ≤ 50V DC

Insulation Voltage : ≤ 100M Ohm 250V DC

Working Life : ≤ One Million Times

Work Temperature : -40 Centigrade-70 Centigrade

Work Humidity : 40 Centigrade-≤ 98%RH

Basic Material Pressurization : 1500V DC

Contact Now

Electric Flexible Printed PCB Rigid Board Multilayer Circuit Board

We are a professional manufacturing company with comprehensive production systems and stable technical personnel. We provide complete one-stop service solutions for flexible printed circuit boards.

Layer Structure

Overlay
Overlay adhesive
Dome retainer
Metal dome
Spacer adhesive
Circuit
Rear adhesive (customizable)

Production Capabilities

Screen Print Department
IR Tunnel
Thickness Tester
IR Oven
Laser Cutting Machine
Punching Department
Emboss Key Section
Assemble
Electric Testing
OQC Department
Virtual Aspect Testing
Punch Machine Department
PU Coating Section

Technical Specifications

Wire Resistance	≤ 1 Ohm/cm
Current Rating	25-100mA, 0-30V DC
Work Voltage	≤ 50V DC
Insulation Voltage	≤ 100M Ohm 250V DC
Working Life	≤ One Million Cycles
Work Temperature	-40°C to 70°C
Work Humidity	40°C ≤ 98%RH
Basic Material Pressurization	1500V DC

Detailed Performance Parameters

Insulation Resistance	<100MΩ, 250V DC
Contact Resistance	<1Ω/cm
Operating Voltage	≤ 50V DC
Working Current	25-100mA, 0-30V DC
Reliability/Service Life	>1 million cycles
Operating Humidity	40°C <98%RH
Spring Time	≤ 5ms
Substrate Voltage	2000V DC
Tail Flexibility	Any angle within 180 degrees
Switch Travel	Flat Type: 0.05-0.3mm, Tactile Type: 0.3-1.5mm

Product Images

Electric Flexible Printed PCB Rigid Board Multilayer Circuit Board

Please contact us for more detailed information and technical specifications. Let's discuss your specific requirements!
